Hantek 6254bd 4 Channels 250MHz Bandwidth Digital Osiklloscope USB PC Portable Osciloscopio Diagnostic Tool with 25MHz Signal Generator
characteristics
Meet or exceed the performance of bench oscilloscopes, four independent analog channels, 1gsa/s high-speed real-time sampling, 2mv-10v/div high input sensitivity, 250MHz high bandwidth.
Pass/fail test, rich trigger functions, dynamic cursor tracking waveform recording and playback and desktop oscilloscope-like interface, easy to use, cost-effective.
USB 2.0 interface, plug and play, free external power supply.
Excellent industrial design, compact, easy to carry, and the shell is made of anodized aluminum of the iPad, not only beautiful, but also improves the alloy surface hardness, good heat resistance and abrasion resistance.
More suitable for tablet PC, notebook computer, product line maintenance, easy on business.
Software support: windows10, windows 8, windows 7
Waveform data can be time and voltage output to excel, bmp, jpg.
More than 20 kinds of automatic measurement functions, pass/fail check, suitable for technical applications.
Waveform average, persistence, intensity, invert, addition, subtraction, multiplication, division, X-Y display.
Fft spectrum analysis.
A computer can connect many dso, extend channel easily.
Usbxi standard interface, easy to put usbxi chassis, consisting of a combination of instruments.
Secondary development library dll provides, labview\vb\vc\qt developer example
specification
Model: Hantek6254bd
Bandwidth: 250MHz
Channel: 4 ch
Real-time sampling rate: 1gsa/s
Memory depth: 64k
Time base precision: ±50ppm
Time base range: 2ns/div-1000s/div (1-2-4 sequences)
Input impedance: 1mΩ 25pf
Input sensitivity: 2mv/div ~ 10v/div
Vertical resolution: 8bit
Bandwidth: 20mhz
Trigger mode: Edge, Pulse, Video, Alternative
Trigger source: Ch1, ch2, ch3, ch4
Waveform signal process: +,-, X, ð, fft, invert
Measurement of cursors: cross, track, horizontal, vertical
Volume: 175mm*105mm*25mm
Weight: 0.9kg
Accessories: 2 passive probes, 2 Gator clip lines
Package included
1 x 6254bd USB Oscilloscope;
2 x Oscilloscope Probe;
2 x BNC clip cable;
1xbnctobnc;
1 x USB Cable;
1 x cd (driver/manual...inside)
