The GD-02 is a flammable gas detector with color displays, offering stable performance, safety, and reliability. It accurately detects methane gas concentrations in the environment. The device boasts excellent anti-interference capabilities, adapts to most environments, and is suitable for various scenarios.
Key Features:
1. Product Features and Performance Benefits
The GD-02 flammable gas detector is designed for high-precision methane gas detection and ambient temperature and humidity monitoring, offering a long service life and excellent low-temperature resistance. The detector features outstanding accuracy, excellent repeatability, linearity, and consistency, as well as strong anti-electromagnetic interference capabilities, making it suitable for various complex environments.
The GD-02 flammable gas detector is designed for high-precision methane gas detection and ambient temperature and humidity monitoring. 2. Flexible Gas Concentration Settings
The device not only supports flexible adjustment of gas concentration thresholds to meet the requirements of different environments and safety standards, but also allows users to select appropriate concentration units according to specific application scenarios to ensure the accuracy and practicality of the measurement data.
3. General Settings and Personalized Functions
The general settings page offers alarm settings (indicator, vibrator, and buzzer), threshold settings (high and low alarm options and numerical adjustment), language switching (Chinese and English), style switching (dark/light mode), and unit switching, among other features, all of which are easy to use and meet various needs.
4. Comprehensive System Settings
The system settings page supports date and time adjustment, sleep settings, brightness settings, factory settings, and volume settings. It is easy to use and offers comprehensive functionality.
Basic Parameters
1. Model Parameter: GD-02
2. Screen Material: 2.0-inch color screen
3. Detectable Gases: Methane, Propane, Isobutane
4. Measuring Range: 0~50,000 ppm (methane), 0~100 (A% LEL)
5. Resolution: 1 ppm/1% LEL
6. Measuring Range (% LEL): 0 ~ 100
7. Operating Temperature: -10 ~ 55°C
8. Warm-up/Response Time: approx. 15–16 seconds
9. (T90): <5 s
10. Recovery Time (T10): <10 s
11. Lifespan: >3 years
12. Sampling Time: ≈0.5 s
13. Dimensions: ≈63×28×139(+360) mm
14. Product Weight: ≈296g
Packing List
1. GD-02 *1
2. Storage Bag *1
3. Data Cable *1
4. User Manual *1
5. Packaging Box *1
