1. Product Overview
The input level/water level transmitter uses a diffusion silicon chip to encapsulate the diffusion silicone oil-filled core within a stainless steel housing. The front protective cap acts as a protective sensor membrane and also ensures smooth contact between the liquid and the membrane. The wire and housing are sealed and connected. The vent tube is connected to the outside of the cable. The internal structure is designed to prevent condensation. An integrated micro-signal processing circuit can be used for long-distance transmission. It features good stability and reliability.
``` 2. Application Area
Widely used in aquatic plants, wastewater treatment plants, municipal water supplies, elevated baths, wells, mines, industrial baths, water tanks, oil baths, hydrogeology, reservoirs, rivers, oceans, and other locations
3. Technical Parameters
◆ Fully enclosed circuit with moisture, condensation, and leak-proof features
◆ Range: 0~200 meters
◆ One-piece design
◆ Accuracy: 0.5% FS
◆ Dimensions: approx. 145 mm, diameter: 28 mm
4. Technical Parameters:
Measuring type and range: 0-1-200 mH2O
Allows 2x scale overload
Operating temperature: -20~60°C
Temperature compensation: -10~60°C
Storage temperature: -40~80°C
Output signal 4-20mA
Power supply
Sensor: 10~30 VDC (standard voltage 24 VDC)/Controller: 85~260 VAC
Housing material: 304 stainless steel (Unless we mark the material as 316, others are 304)
Cable: Waterproof, breathable cable
Protection class: IP68
