T9-130S Ultrasonic Thickness Gauge Description:
【Main Purpose】 This ultrasonic thickness gauge is an intelligent, portable ultrasonic thickness gauge. Controlled by a microprocessor, it uses the principle of ultrasonic measurement to quickly and accurately measure the thickness and sound velocity of a variety of materials.
【Accurate Measurement】: This ultrasonic thickness gauge features single-chip microprocessor technology, a resolution of up to 0.01 mm, stable measurement, and fast response speed. It can be used to accurately measure various materials or parts in industrial production, and it can also monitor various pipelines and pressure vessels in production facilities. It can accurately measure the degree of thinning of different parts over time during use.
【Accurate Measurement】: This ultrasonic thickness gauge uses single-chip microprocessor technology, a resolution of up to 0.01 mm, stable measurement, and fast response speed. Wide range of applications: Metals, plastics, ceramics, glass, and other good conductors of ultrasonic waves, as long as there are two parallel top and bottom surfaces, can be used to measure the thickness of materials such as aluminum, copper, gold, resin, water, glycerin, etc. Cast iron is not suitable for this device because its internal grains are too coarse.
【Measuring Range】 Measuring range: 1.0-350 mm, 0.01 data storage units, Measurement resolution: 1.00 mm (99.99-0.1 mm), 350 mm (- mm)
T9-130D Ultrasonic Thickness Gauge Specification:
Measuring range: 1.0-350 mm
Operating frequency: 5 MHz
Lower limit of pipe measurement: 20 x 3 mm
Resolution: 0.01 mm (1.00-99.99 mm), 0.1 mm (350- mm)
Accuracy: h <10 mm: ± 0.05 mm, 10-99 mm: ≤ ± 0.01 + h/200 mm, >100 mm: ≤ ± 0.1 + h/100 mm
(H thickness of the material being measured)
◆ Power Supply Battery Specification: 3 x 1.5V AA alkaline batteries, lasts approximately 20 hours
◆ Built-in 11 sets of commonly used material sound velocity values for user selection and use
Customer-specific and adjustable sound velocity function, adjustable sound velocity range: 1000 ~ 9999 m/s
4mm self-calibration function
LCD backlight can be selected to turn the function on or off
Operating temperature: 0°C ~ 40°C; Probe: 0°C ~ 60°C
◆ Net weight of the device: 153g (including protective case, but excluding battery)
◆ Ultrasonic thickness gauge device dimensions: 72 x 135 x 36 mm
Package contents: (Battery not included)
1 x Ultrasonic Thickness Gauge (Model: 130d)
1 x 5MHz/10 probe
1 x case
1 x user manual
1 x carrying hard case
