HDMI Video Mixer and Switcher for Live Streaming – 4 Channel with PIP and Audio Mixing
This professional HDMI video switcher is designed for live streaming, broadcasting, interviews, conferences, and video recording. With four HDMI inputs and two HDMI outputs, it enables fast switching and mixing of multiple video sources in real time.
The device supports 1080p@60Hz HDMI signals and HDCP 1.4. Thanks to automatic signal processing, various input resolutions are adapted and transmitted with a stable 1080p@60Hz output.
With features such as PIP (Picture-in-Picture), split screen, preview/program preview, fade transitions, and cut switching, this video mixer is ideal for professional live productions.
The integrated audio control supports HDMI audio, MIC 1/2, and LINE IN with audio mixing, as well as a LINE OUT output. The USB-C 3.0 port allows video signal transmission for streaming and recording.
Features
4 × HDMI inputs, 2 × HDMI outputs
Supports 1080P@60Hz video resolution
PIP, Split Screen, FTB, AUTO, and CUT functions
HDMI audio + MIC + LINE IN audio mixing
USB-C 3.0 capture port (YUY2/JPEG)
OSD display for channel, resolution, and volume
Settings are saved after power-off
Suitable for live streaming, events, training, and broadcasting
Technical Specifications
Input: HDMI × 4
Output: HDMI × 2
Output resolution: 1920 × 1080 @ 60Hz
Audio format: PCM
USB-C Capture: YUY2, JPEG
Power supply: DC 12V / 2A
Dimensions: approx. 180 × 115 × 52 mm
Operating temperature: -15℃ to +55°C
Package contents:
1 × HDMI video mixer
1 × USB-C 3.0 cable
1 × DC 12V power adapter
1 × User manual
